Electrical material

The DDSU666-H is Huawei's single-phase smart meter for photovoltaic systems: it measures current, voltage, power and energy with an LCD display, communicates via Modbus-RTU RS485 with SUN2000 inverters and mounts on a DIN35 rail.

The DTSU666-H is Huawei's three-phase smart power sensor: it measures current, voltage, power and energy with class 1 accuracy, an LCD display, Modbus-RTU RS485 communication and DIN35 rail mounting. For monitoring production and consumption with SUN2000 inverters.

Huawei Smart Meter for three-phase installations - up to 80A if mounted in direct insertion - > 80A if mounted with external CTs - CTs not included

The Huawei EMMA-A02 is the smart energy management assistant for single-phase and three-phase PV systems: it optimises production, self-consumption, storage and home loads, coordinating inverter and batteries through FusionSolar. Up to 63 A (higher with 50 mA CTs).

The Huawei SmartLogger 3000A01EU is the data logger for centralised monitoring of photovoltaic systems with up to 80 devices (SUN2000 inverters, LUNA2000 batteries, sensors), integrated with FusionSolar.
Integrated 4G, Ethernet WAN/LAN, 3 RS485 ports up to 1,000 m, Modbus-TCP and IEC 60870-5-104, web server and export limitation function (requires a meter). IP20 indoor, -40/+60 °C. Version without PLC module: for powerline use the 3000A03EU.

The SecSun UBM1101L is an AC/DC combiner box (string box) for single-phase photovoltaic systems up to 3 kW, 1 string: integrated DC and AC disconnectors, surge arresters and RCBO. IP65, class II, EN 61439 compliant.

The SecSun UBM2102L is an AC/DC combiner box (string box) for photovoltaic systems up to 6 kW with 2 strings (600 VDC, 16 A): integrated DC and AC disconnectors and surge arresters. IP65, class II, EN 61439 compliant.

The SecSun UBM-57260 is an AC/DC combiner box (string box) for single-phase photovoltaic systems up to 6 kW with 2 independent strings at 1000 VDC: integrated DC and AC protections. IP65, class II, EN 61439 compliant.

The SecSun UBM-57260.1 is an AC/DC combiner box (string box) for single-phase photovoltaic systems up to 3 kW, 1 string at 1000 VDC: integrated magnetothermic, differential and surge protections. IP65, class II, EN 61439 compliant.

UBT2102L three-phase AC/DC combiner box, 10 kW, 2 independent strings at 1000 VDC. Integrated protections (MCBs, RCDs, surge arresters), IP65. 340 × 622 × 161 mm.

UBT-57260.2 three-phase AC/DC combiner box, 10 kW, 2 independent strings at 1000 VDC. Integrated protections (MCBs, RCDs, surge arresters), IP65.

SecSun UBM1101 AC/DC combiner box, single-phase 3 kW, 1 string. Integrated DC/AC protections (fuse-isolators, surge arresters, RCBO), IP65. 432 × 340 × 161 mm, EN 61439.

SecSun UBM2102 AC/DC combiner box, single-phase 6 kW, 2 independent strings. Integrated DC/AC protections (fuse-isolators, surge arresters), IP65. 622 × 432 × 161 mm, EN 61439.

UBT2102 three-phase AC/DC combiner box, 10 kW, 2 independent strings. Integrated protections (MCBs, RCDs, fuses, surge arresters), IP65. 622 × 432 × 161 mm.

DC Light panel 1000VDC 1 string Measurements 200x 200 x 115 mm (WxHxD)

DC Light panel 600VDC 1 string Measurements 200 x 200 x 115 mm (WxHxD)

DC Light panel 1000VDC 2 independent strings Measurements 340 x 432 x 161 mm (WxHxD)

DC Light panel 600VDC 2 independent strings Measurements 340 x 432 x 161 mm (WxHxD)

DC Light field box 1000VDC 4 independent strings: 4× 2P fuse holders 16A-1000VDC, 4× isolators 16A, 4× surge arresters, wall-mount PVC IP65.

SecSun QCM-511706 DC field combiner box for 8 PV strings, DC Class II SPD, sectionable fuse holders, IP66. Made in Italy. 510 x 720 x 250 mm, 5 kg. For commercial/industrial PV.
