Batteries

Marstek B2500 is the first lithium storage system for balcony photovoltaic systems.
Simple to install and compatible with all microinverters on the market, B2500 allows for the optimization of balcony photovoltaic systems.

SolaX HR140 Rack for 7 TB-HR140+1 BMS modules. 100.1kWh C&I system with LFP 280Ah batteries, 0-53°C charge / -20-53°C discharge, >6000 cycles life and 10 year warranty.
IP20 indoor design, IEC 62619/62477/UN 38.3 certifications, compatible with Aelio Solax systems only. 100-200 kWh configurations available.

The SolaX BMS Parallel Box II G2 connects SolaX Triple Power T58 batteries in parallel in a Master/Slave configuration (a T58 Master battery is required). It lets you expand storage capacity beyond a single tower, with system management and integrated protections.

Master module of the SolaX Triple Power V3 high-voltage storage system: 5.8 kWh nominal capacity with LFP technology and integrated BMS, the only module in the range that can operate on its own. 95% depth of discharge (5.5 kWh usable), over 6,000 cycles, 10-year warranty, IP66 for outdoor installation as well. Expandable up to 34.6 kWh with HV11550 V3 slave modules.

Slave expansion module with 5,8 kWh LFP for the SolaX Triple Power V3 high-voltage storage system. It does not include the BMS and does not work on its own: it must be connected to a T-BAT H 5.8 V3 master module, up to five slaves per tower (34,6 kWh total). 95% depth of discharge, over 6.000 cycles, 10-year warranty, IP66.

ZZT-ZBT5K-EXT-KIT extension kit to add the 4th/5th HV ZBT 5K battery to the ZCS Azzurro storage system, positioned alongside in a second tower (not stacked). Includes additional base and parallel connection cables.

ZST-CABLE-KIT cable kit for connecting ZCS Azzurro single-phase hybrid inverters to LV ZSX5000 batteries or Pylontech US2000/US3000 packs. Orange/black power cables, 5-meter length.

150 cm parallel interconnection kit for linking two ZCS Azzurro ZSX5000 battery modules or two storage boxes. Includes both the power cables and the BMS communication cable.
This is the long version, needed when the two battery packs are installed some distance apart, for example on separate walls or in separate cabinets. It is not the battery-to-inverter cable, which is the separate ZST-CABLE-KIT part number.

High-voltage battery module ZCS Azzurro ZZT-BAT-ZBT5K, 5,12 kWh nominal, 400V, stackable up to 4 modules (20,48 kWh). Compatible with ZP1 and ZP3 inverters. IP65, external BDU required.

Single-phase all-in-one storage system from ZCS Azzurro for retrofit: a 2.5 kW inverter and a 5.12 kWh LiFePO4 lithium battery in a single wall-mounted appliance.
AC coupled: it is added to an existing photovoltaic system without replacing the inverter. Expandable with several units in parallel.

Battery Distribution Unit (BDU) for ZCS Azzurro high voltage storage systems using 5.1 kWh ZBT 5K modules. It is the base unit of the tower, housing the BMS, the DC protection devices and the link to the inverter.
IP65 rated, inverter connection cables included. One BDU is required per battery tower, with 1-4 modules per tower.

ZCS Azzurro ZSX5000-S LiFePO4 lithium battery (ZZT-BAT-5KWH-Z5S), nominal capacity 5,1 kWh, compatible with single-phase HYD-HP inverter 3,6-6 kW. IP65, up to 4 modules in parallel, 10-year warranty.

SolarEdge SE-BI-EU 3P (BI-EU3P) backup interface for full or partial home backup on three-phase Home Hub inverters with battery. Integrated meter, IP65, 12-year warranty. To be purchased separately from the inverter.

SolarEdge SE-BI-EU 1P Backup Interface (BI-EU1P) for full or partial home backup on single-phase Home Hub inverters with battery. IP65, up to 100 A and 3 inverters in parallel. To be purchased separately from the inverter.

SolarEdge IAC-RBAT-RWYCBL-01 Y-cable kit for connecting multiple Home 48V batteries in parallel to the same Home Hub or StorEdge inverter. Dedicated MC4 connectors, not replaceable with generic adapters.

IAC-RBAT-HANDLE-01 handle for handling the SolarEdge Energy Bank battery, especially useful for wall mounting. The package contains 1 piece, but 4 are required per battery: this is the most common ordering mistake for this accessory. It is not part of the final installation and can be reused for subsequent jobs.

SolarEdge IAC-RBAT-FLRSTD-01 floor stand kit for the Energy Bank / SolarEdge Home Battery 10 kWh.
It includes the base mount and the rear holder and is the alternative to wall mounting when the wall is not suitable. One kit per battery; multiple stands can be placed side by side and secured to each other.

SolarEdge ENET-HBPV3D-01 upgrade kit: includes communication board with LCD display, SolarEdge Home Network plug-in and antenna.
It brings single-phase HD-Wave inverters with display (not Home Network ready from the factory) up to the current communication standard, enabling the SolarEdge Home Battery / Energy Bank and wireless control of Smart Energy devices.

Energy Net ENET-HBNP-01 plug-in module for wireless communication between SolarEdge inverters, Energy Bank battery and SolarEdge Home devices. This is the version for inverters already Energy Net ready (codes with BE), so it does not include the communication board and costs less than the complete kit. One is required per inverter. External antenna included.
