Microinverter DEYE SUN300G3-EU-230 - per impianti fino a 400W

CARATTERISTICHE:

Flessibile ed espandibile, Alto rendimento, Peso ridotto, Installazione semplice.

Montaggio a parete con guida din, montaggio in esterno

Model: DEYE SUN300G3-EU-230

Input Data (DC)

Recommended input Power (STC): 210~420W (1 Pieces)

Maximum input DC Voltage: 60V MPPT

Voltage Range: 25~55V Full Load DC

Voltage Range (V): 24.5~55V

Max. DC Short Circuit Current: 16A

Max. input Current: 1×10,5A

Output Data (AC) Rated output Power: 300W

Rated output Current: 2.6A

Nominal Voltage / Range (this may vary with grid standards): 230V/0.85Un-1.1Un

Nominal Frequency / Range: 50 / 60Hz

Extended Frequency / Range: 45~55Hz

Power Factor: >0.99

Maximum units per branch: 17

Efficiency CEC Weighted

Efficiency: 95% Peak

Inverter Efficiency: 96.5%

Static MPPT Efficiency: 99%

Night Time Power Consumption: 50mW

Mechanical Data Ambient Temperature Range: -40~65℃

Size (mm): 212W×230H×40D (Without mounting bracket and cable)

Weight (kg): 3.15

Cooling: Natural cooling

Enclosure Environmental Rating: IP67

Features Compatibility: Compatible with 60~72 cell PV modules

Communication: WIFI / Zigbee Grid Connection

Standard: VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150

Safety EMC / Standard: UL 1741, IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3

Warranty: 10 years
