MRX65MF - Flexible solar panel 65W 12V Mono, size 100x40cm
The MRX65MF photovoltaic module is equipped with a high level of efficiency.
This series is particularly suitable for all applications where the available installation space is limited (such as campers and boats), while still allowing for high production capacity.
The photovoltaic modules are made with high-efficiency monocrystalline silicon cells.
The photovoltaic module is of the ETFE-tedlar type, the result of a careful selection of the best materials available on the market and advanced processing technology, entirely MADE IN ITALY.
The cells are vacuum encapsulated between two sheets of EVA with an upper layer of a plastic polymer called ETFE, which is highly resistant to corrosion and damage from atmospheric agents, making it self-healing.
The FLEX series modules are designed to ensure maximum performance even in mobile applications such as campers or boating (ETFE), where the modules are often installed with non-ideal tilt and azimuth.
ELECTRICAL CHARACTERISTICS:
Maximum Power (Pmax) 65Wp
MPP Voltage (Vmax) 12V
PHYSICAL CHARACTERISTICS:
Dimensions (mm) 1000 x 400 x 3
Backsheet color: Black
Other: 3+3 eyelets on the long sides
CONSTRUCTION CHARACTERISTICS:
Module production location Italy
Cell type Monocrystalline
Number of cells 24
Front side Transparent ETFE
Back side Multilayer Tedlar
Encapsulation EVA
Frame None
Junction box IP65-2 bypass diodes on the front
