Alfen 905661015 Load Balancing License | EV Charging
Alfen 905661015 software licence for Eve Double charging stations: enables Active Load Balancing and Smart Charging Network. It adapts charging to the site's consumption and distributes power among several connected charge points.
The Alfen 905661015 licence is a software configuration for Eve Double charging stations that combines two smart charging functions: Active Load Balancing and Smart Charging Network. It is not a physical device and does not replace the energy meter, the data network or the system configuration: it enables the compatible functions on the Alfen station.
What do Active Load Balancing and Smart Charging Network do?
Active Load Balancing measures the power used by the installation, through a compatible system or external meter, and adjusts the current available for charging. The station can thus reduce its demand when other loads rise and recover power when consumption falls. Smart Charging Network connects several Alfen stations and distributes the power assigned to the charging network among the vehicles.
Alfen 905661015 licence specifications
| Code | 905661015 |
| Product type | Software licence and configuration |
| Function 1 | Active Load Balancing |
| Function 2 | Smart Charging Network |
| Indicated range | Alfen Eve Double Pro-line |
| Activation | Licence code entered in the station configuration |
| Physical product | No |
Requirements to check before buying
Compatibility depends on the model, hardware platform, firmware and options already active on the station. Active Load Balancing also requires a compatible data source and correct configuration, for example an external Modbus TCP/IP meter or another supported interface. For Smart Charging Network, the stations must be able to communicate over the local network planned in the project.
What is included?
- Alfen software licence, code 905661015.
- Activation of the ALB and SCN functions for the purchased configuration.
- Code needed to unlock the function on the compatible station.
Wallbox, smart meter, network switch, cables, installation and technical configuration are not included in the licence.
Frequently asked questions
Is licence 905661015 a wallbox?
No. It is a software product that enables smart functions on a compatible Alfen station. The charging station must be purchased separately.
What is the difference between ALB and SCN?
ALB adjusts charging power according to the site's total consumption. SCN coordinates several stations and shares the available power among them. The two functions can work together.
Is an external meter required?
Active Load Balancing needs a measurement source compatible with the Alfen configuration. The model and protocol must be checked before purchase and activation.
Is the licence activated automatically after ordering?
No. Smart functions are paid options unlocked by entering the licence code in the station configuration, using the Alfen tool or a compatible back office.
Is the licence compatible with any Eve Double?
Do not take it for granted. Check the exact model, platform, firmware, number of sockets and options already present. If in doubt, provide the station code before ordering.
