Sale! Solar Charge Controller EPIP30 30A 12V/24V View larger

Online only

Solar Charge Controller EPIP30 30A 12V/24V

EPIP30

New product

Solar charger controller EPIP30 30A 12V/24V

IdeaArticle recommended for small projects realization

More details

9 Items

in stock

By buying this product you can collect up to 2 loyalty points. Your cart will total 2 loyalty points that can be converted into a voucher of 0,10 €.


25,85 € tax excl.

Data sheet

Equalization voltage14.8 V
Boost voltage14.4 V
Float voltage13.6 V
Low voltage disconnect (LVD)11.10 V
Low voltages reconnect (LVR)12.6 V
Temperature compensation-30mv/ /℃ 12V
Self-consumption6mA maximum
Terminalsfor wire sizes to 6mm2
Temperature -35℃ to +55℃
NoteX2 for 24V system
Output Voltage12V 24V auto switch
Max load current ≤30A
Full charge cut13.7 V
Low voltage cut10.5 V
Temp compensation-3mv/℃/cell
Zero Load Loses≤20mA
Voltage Drop less than 160mv

More info

Solar charger controller EPIP30 30A 12V/24V

A solar charge controller is the controlling center of the PV battery in off-grid power system which makes use of solar cells array to protect your batteries from being over-charge and over-discharge, so the life span of it can be extended.

All technical information are available on enclosed datasheet
