NanoSolar nanocell Flexible CIGS solar cell 6"x5" inches (156X135 mm) A-grade 2,6W power
|Article recommended for DIY solar panels|
17 Item Items
Warning: Last items in stock!
No reward points for this product.
|Height (inches)||6 inches|
|thickness (mil)||0,5 mm|
|Weight (Oz)||20 g|
|Power (W)||2,6 W|
|Voltage (V)||0,55 V|
|Current (A)||5,8 A|
|Property||Lightweight Aluminum Structure CIGS Solar Cells which are Semi-Flexible|
Nanosolar NanoCell 2.6 Watt LIghtweight Flexible Aluminum CIGS MWT Solar Cells. These are rated at about 0.45 volts at 5.8 amps and are a flexible cell made on a semi rigid but flexible aluminum base. We have found conductive glues or epoxy the best way to connect these cells.
These raw flexible solar cells are extremely rare and have never been offered for sale to the public before.
These are raw solar cells and will degrade if not encapsulated in weather tight enclosure. Also they are made of aluminum and to connect them you will need to use a conductive glue or special Alumiflux rosin with solder. Nanosolar used an ultrasonic welder to connect the cells in production.
The large area of metal (nickel coated aluminum) back is the positive output of the cell. The thin strip of uncoated aluminum on the front is the negative output of the cell.
Our DIY solar panels help families to save energy, money and protect environment.
These kits are the cheapest way to provide electricity by the sun and are perfects for small/medium projects such as boats, camper and camping, garden, small appliances and more.
Building solar panels is highly educational and entertaining, they are also versatile, because you can suite voltage/current to your needs in a way that it's impossible with pre-assembled ones.
A typical configuration is 36 cells in a single panel for about 18 volts and up to 3,8 amperes;In configuration 3x12 cells, final panel size are about 50x100cm
If you're beginner and want further useful tips howto soldering solar cells and all components you need to start job, can read our Learning ZONE article that explain everything step-by-step with a demo video too.
We have been using a 3M / Tapecase 1182 double sided conductive copper tape to connect them for testing.
