Online only

KIT 12W solar DIY composed by 12 polycrystalline solar cells 3"x3" inches (78X78 mm) A-Grade with soldering assembly kit

K12P-3x3-A

New product

KIT 12W 12 solar cells 3"x3"  (78X78mm) A-grade

IdeaThis affordable product is recommended for DIY solar photovoltaic module

More details

13 Items

In stock

By buying this product you can collect up to 1 loyalty point. Your cart will total 1 loyalty point that can be converted into a voucher of 0,05 €.


16,90 € tax excl.

Data sheet

Power (W)12 W
Solar cells12x Poli 3"x3" (78x78mm) 0.55V 1.8A
Diodes1x schottky Diode 5A 100V
Flux1x Dispenser 10ml Stannol flux x32-10i
Tab wire3m (10') 0.15x2mm

More info

KIT 12W solar DIY composed by 12 polycrystalline solar cells 3"x3" inches (78X78 mm) A-Grade with soldering assembly kit

Our kits of DIY solar panels are the cheapest way to provide electricity from the sun and are perfect for stand-alone installations, which is isolated from other energy sources such as the national grid; usage applications are many, such as boats, mobile homes or camping in general, garden lights lighting, small appliances, electronics and much more.

Building panels is highly educational and fun, they are also versatile in that you can customize voltage / current / dimensions to suit your needs, something not possible with pre-assembled solar panels.

If you are a beginner and want to learn more about the cells and tips on how to make the welds and all the components you need, you can read our articles in the Learning Zone an watch our video tutorials

We always add some cells to compensate the breaks during welding or during transportation, in any case for any problem due to sending please contact us and we will do our best to solve all your problems, because the important thing for us it is that you remain 100% satisfied.

Notes:

In all PV systems Island (then with batteries), it is essential the use of charge controllers to prevent overcharging of batteries that are not too rare cases can cause the explosion of the battery (see electrolysis).

It will be very important to mount the solar cells efficiently to ensure long life of the panel, low risk of corrosion and cracking. There are several options to achieve a good result like the encapsulation of cells within a double glazed window, the use of silicone resins as special QSIL 216 or use sheets of EVA to name just a few examples. In the Learning Zone of our website you can find other more economical methods to achieve a good result.

It is also advisable to use a soldering iron of 60W - 80W and no less powerful with flat point. You must also have the cells on a smooth surface of glass or other thermally insulating materials.

If you need more informations about how to build your own solar module from the beginning, please watch below video or our youtube page.
